Oracle 11G Installation on Linux

Red Hat Linux (6.6)

Step 1:-

Check for proper rpm installed or not by using rpm –q |grep <rpm name>.

List of all RPM’s needed-

binutils-2.20.51.0.2-5.11.el6 (x86_64)

compat-libstdc++-33-3.2.3-69.el6 (x86_64)

glibc-2.12-1.7.el6 (x86_64)

ksh-*.el6 (x86_64)    <== any version of ksh is acceptable

libaio-0.3.107-10.el6 (x86_64)

libgcc-4.4.4-13.el6 (x86_64)

libstdc++-4.4.4-13.el6 (x86_64)

make-3.81-19.el6 (x86_64)

compat-libcap1-1.10-1 (x86_64)

gcc-4.4.4-13.el6 (x86_64)

gcc-c++-4.4.4-13.el6 (x86_64)

glibc-devel-2.12-1.7.el6 (x86_64)

libaio-devel-0.3.107-10.el6 (x86_64)

libstdc++-devel-4.4.4-13.el6 (x86_64)

sysstat-9.0.4-11.el6 (x86_64)

New set:

binutils-2.20.51.0.2-5.11.el6 (x86_64)

compat-libcap1-1.10-1 (x86_64)

compat-libstdc++-33-3.2.3-69.el6 (x86_64)

compat-libstdc++-33-3.2.3-69.el6.i686

gcc-4.4.4-13.el6 (x86_64)

gcc-c++-4.4.4-13.el6 (x86_64)

glibc-2.12-1.7.el6 (i686)

glibc-2.12-1.7.el6 (x86_64)

glibc-devel-2.12-1.7.el6 (x86_64)

glibc-devel-2.12-1.7.el6.i686

ksh

libgcc-4.4.4-13.el6 (i686)

libgcc-4.4.4-13.el6 (x86_64)

libstdc++-4.4.4-13.el6 (x86_64)

libstdc++-4.4.4-13.el6.i686

libstdc++-devel-4.4.4-13.el6 (x86_64)

libstdc++-devel-4.4.4-13.el6.i686

libaio-0.3.107-10.el6 (x86_64)

libaio-0.3.107-10.el6.i686

libaio-devel-0.3.107-10.el6 (x86_64)

libaio-devel-0.3.107-10.el6.i686

make-3.81-19.el6

sysstat-9.0.4-11.el6 (x86_64)

Step 2:-

Then we need to check for Kernel Parameter. The minimum value for the same is listed below-

cat /etc/sysctl.conf—–this file needs to change and after change run below command

sysctl -p

Kernel Parameter Settings -

kernel.shmall = 4294967296

kernel.shmmax = 68719476736

kernel.shmmni = 4096

kernel.sem = 250 32000 100 128

fs.file-max = 6815744

fs.aio-max-nr = 1048576

net.ipv4.ip_local_port_range = 9000 65500

net.core.rmem_default = 262144

net.core.rmem_max = 4194304

net.core.wmem_default = 262144

net.core.wmem_max = 1048576

Step 3:-

Then add the following settings to /etc/security/limits.conf

oracle           soft      nproc      2047

oracle           hard     nproc     16384

oracle           soft      nofile      1024

oracle           hard     nofile      65536

Step 4:-

Then verify the latest version of PAM is loaded, then add or edit the following line in the /etc/pam.d/login file, if it does not already exist:

session        required      pam_limits.so

Step 5:-

User Creation:-

#  useradd -g dba oracle

#  groupadd dba

#  id oracle

# passwd oracle     [to set the password]

# cat /etc/passwd|grep -i oracle

# cat /etc/group|grep -i dba

For deletion –

# userdel -r oracle

Step 6:-

Then we need to create the filesystem-

# mkdir oracle

# chmod 775 oracle

# chown -R oracle:dba oracle

&

# mkdir oradba

# chmod 775 oradba

# chown -R oracle:dba oradba


export DISPLAY=10.201.64.102:0.0

export ORACLE_HOME=/d01/oracle/product/v.11.2.0.4/

export PATH=$ORACLE_HOME/bin:$ORACLE_HOME/lib:/usr/ccs/bin:/usr/bin:/usr/local/bin:/opt/bin:/usr/sbin/:/sbin:/bin:.
